Input:

• Selectable 115VAC 60 Hz/230VAC 50/60 Hz input. - 115VAC 60 Hz., 4 amp - 230VAC 50/60 Hz., 2.5 amp Output:

• Sixteen (16) individually selectable 24VAC or 28VAC power outputs with OFF position.

• 24VAC or 28VAC @ 14 amp total output current.

• Sixteen (16) external blade fuse protected outputs rated @ 3 amp (VertiLine166).

• Sixteen (16) PTC protected outputs rated @ 2.5 amp (VertiLine166D).

• Main fuse rated @ 15 amp.

• Surge suppression. Visual Indicators:

• Sixteen (16) individual power LEDs.
